NetworX 12 Alarm Repairs Services - DAS - Callout service
NX12 Keypad repairs - User pin code reset - code pad servicing replacements
We service NX12 alarm system to LED Vertex keypads, NX12 alarm panels, wireless battery devices, wireless remote receivers, remote control key fobs to your security system. We provide alarm battery replacements, technical programming assistance and code resets to your existing NetworX NX12 burglar unit for fast call out servicing.
We repair NX12 keypad - Red Power light flashing - Service light indicator ON - Alarm beeping keypads - system code resets - NX12 battery replacements - Keypad repairs - Service error fault - Unexpected false alarming - Emergency switch OFF security system - Smoke alarm service - Expander trouble - Fire light flashing - Siren fault trouble - Tamper zone faults fixed - If you cannot turn on your alarm system - Open zone faults - Wireless NX12 sensor battery replacements
Does your existing NX12 system have remote controls for arming and disarming? Alarm Maintenance can supply and install to your premises including hard-wired and wireless equipment! We can connect key fobs to lots of old and existing control panels
NBN issues to your alarm system
In most areas in Australia the National Broadband Network will not function to most NX12 alarm systems to connect to your mobile devices. A fault indicator, service light or beeping sound happens when your system attempts to send signals to a monitoring company or smart phone with no successful connection. In this case there is a communication fault caused by the NBN. So now best to call your network service provider to check this out with the phone technical support team. In most cases you will now be required to fit an IP module connected to the internet for text messaging alerts.
Alarm Maintenance service many more NetworX security systems for domestic and commercial to protect to your family, home and your property.
Features
12 different programmable zones
Expandable to Remote Controls
Maximum of 8 keypads
ITI wireless communication devices compatible and many different wireless devices
Sleep Mode - Stay Mode - Arm Mode
Aux Output Main Controller
Event Programming Features
Instructions for NX12 ALARM SYSTEM
How to ARM your alarm system from your code pad
Ensure the green READY light is on (areas are sealed) close the doors and windows
Enter USER CODE eg. 6 9 3 9 or just press the "ON" button
Make sure that the red ARMED & Green ON light illuminates
If any of the zones are isolated, a sensor in that zone can give a mixed reading affecting the "READY" light (green light flashing). The security system will not arm if the "READY" light is not illuminated green. With the "READY" light on, you may arm the security system with your 4 digit Code. Each time a key is pressed on the keypad, a short tone (beep) will sound. If the code pad beeps three times after a code entry, it is an indication that the code has not been accepted. Press the [#] key (reset) and re-enter a valid code. The code pad sounder can be quietened by re-entering your pin code. When the security system has accepted a valid code, the red "ON" light will illuminate indicating that the system has been turned on. The user must leave within the exit delay time.
How to disarm your NX12 security system
Enter USER CODE eg. [7] [1] [9] [9]if code is 7199 - keypad "ON" light goes OFF
When you return to your property the keypad will sound a continuous tone (beep) for the duration of the entry delay time. Enter a valid code within this entry time and the red "ON" light will turn OFF, and the tone will stop. The security system is now DISARMED. If a valid code is not entered before the end of the entry delay time, an alarm will occur.
How to change the first user code to your NX12 security system
Enter from keypad *5 followed by your 4 digit master code followed by [0][2] followed by new 4 digit user code then press [#] to saveand exit programming
How to change the master code to the security system
1. Press [*] 5 followed by your existing master code eg. [6] [9] [3] [9]if code is 6939
2. enter the two digit user code location code to change Example: [0][1]
3. enter the new four-digit code number you would like eg. [2] [6] [2] [6]if code is 2626
4. press the [#] key to save new number and exit programming
How to set the system date to your NX12 security system
1. On your keypad Press the [*] [9] [6] keys for access to function 96 2. enter your master code Example: [1][2][3][4] if the code is 1234 and Date is 23/10/2020 Friday 3. enter day of the Week code:[1]= Sunday [2]= Monday [3]= Tuesday [4]= Wednesday [5]= Thursday [6]= Friday [7]= Saturday 4. enter the two digit month code [0][1] = January to [1][0] October [1][2] December 5. enter the two digit day of the Month code Example: [0][1]= 1st [2][3]= 23rd [3][1]= 31st 6. finally enter the last two digits of the Year code. Example: for 2020 enter [2][0] followed by the [#] key
How to set the system clock (time)
1. Press the [*] [9] [7] keys for access to function 97 2. enter the master code Example.[1][2][3][4] if the code is 1234 3. enter the hour sequence Example: for 7.40pm enter [1][9][4][0]
Why is my keypad power light flashing on my NX12 alarm
The power light (red LED) will start flashing because this shows that your back-up-battery to the control panel is very low and now needs replacement. When the alarm battery has been replaced and reset properly, the power light will stop flashing showing that the main battery is now in working fine as it should be.
Why is my service light lit "ON" to my NX12 alarm keypad?
The service light (yellow LED) on your key pad light is ON because it requires servicing.
If the service light is "ON" press the [*] star key followed by the [2] number two key to indicate the service condition. The LED or LED`S will illuminate indicating what service needs attending to. Refer to your instructions to locate the issues that is causing this service requirement.
Common issues to your NX12 service light "ON" are a wireless zone low battery, low main battery, loss of zone tamper supervision, faulty devices telephone line fault, loss to communications, fuse fail, reset to system time, expander device trouble, external tamper fault and siren fault.
Does your existing NX12 system have remote controls for arming and disarming? Alarm Maintenance can supply and install to your premises including hard-wired and wireless equipment! We can connect key fobs to lots of old and existing control panels
In most areas in Australia the National Broadband Network will not function to most NX12 alarm systems to connect to your mobile devices. A fault indicator, service light or beeping sound happens when your system attempts to send signals to a monitoring company or smart phone with no successful connection. In this case there is a communication fault caused by the NBN. So now best to call your network service provider to check this out with the phone technical support team. In most cases you will now be required to fit an IP module connected to the internet for text messaging alerts.
How to change the master code to the security system
